For decades now, press brakes have been operated through foot pedals that are hardwired to the machine controls cabinet. While this is the standard method for a safe and reliable connection, foot pedal cables running across the floor tend to get in the way of machine operators, create potential tripping hazards and can make it difficult to move the pedal to a comfortable working position.

All this is about to change with a ground-breaking wireless safety communications technology that enables press brake manufacturers to easily incorporate wireless functionality into their existing foot pedals. The new wireless safety communications technology employs a unique SIL3 communications process that provides remote input and output connections between a remote wireless device and the machine. Wireless foot pedals have several advantages over their wired counterparts in terms of improved ergonomics, reduced operator fatigue, eliminating down-time caused by damaged cables and removing tripping hazards for a safer work environment.

Flexibility to incorporate additional functions

Wireless remote hardware is incorporated into the design of the foot pedal pendant and contains physical inputs for the foot pedal contacts. The wireless pedal is paired with a module on the press brake that is interfaced with the machine safety controller that processes the incoming foot pedal signals.

The addition of remote wireless inputs in the foot pedal now gives press brake manufacturers the flexibility to incorporate additional functions to wireless foot pedal stations. While most wired pedals will include the same base functions such as the down and up pedal switches, manufacturers are now incorporating other wireless controls including buttons for upper and lower tool clamping, an illuminated emergency stop button, machine reset, machine start and stop, plus more.

Extremely low power consumption

A major breakthrough of the new wireless technology is its extremely low power consumption. The method in which the data is transmitted is one of the keys in significantly reducing power consumption and thus eliminating the need for a large battery and frequent recharging. In addition to the energy efficient design, an indoor solar cell is incorporated into the foot pedal pendant that uses ambient light to constantly charge and extend the life of the battery, providing up to 50% of the energy requirements.

Battery Press Brake Wireless Foot Pedal

Up to two months use from a single charge

A single charge can power a wireless foot pedal for up to two months. Of course, press brake manufacturers can opt for larger capacity batteries to extend the time between manual recharges. When the foot pedal does need to be manually recharged, a USB charging port on the foot pedal pendant makes it relatively simple to plug the pedal into a charging port on the machine or through a standard USB charger. The foot pedal can also be connected to the press brake via a quick connect cable for normal wired operation if necessary.

E-Paper display

Also incorporated into the wireless pedal pendant is a 25mm x 65mm E-Paper display. This active display presents a range of useful information for the machine operator including the maximum wireless range and current distance from the machine, connection status, battery level, emergency stop status as well as the status of any optional auxiliary functions. Again, in keeping with the low-power design, the E-Paper display consumes very little energy, putting almost no additional load on the power system.

Support for multiple wireless pedals

Foot pedals are paired with the machine module and press brakes can support multiple wireless pedals when two operators are required to handle the material during bending. Two foot pedals can be easily connected to a single machine and the number of active pedals is selected via the CNC. The pedal station number and active status are updated in real-time and displayed to the machine operator via the integrated E-Paper display.

Users can also take advantage of sharing foot pedals across multiple machines with the ability to pair them to the required machines for certain jobs. This means that fewer foot pedals would need to be purchased as they can be easily shared among multiple machines in a production facility. The paring process is simple and takes only a matter of seconds by pressing and holding the pairing buttons on the machine module and foot pedal until the two are connected.

Of course, there are a few situations that could arise that may be cause for concern with wireless technology. Questions such as “What if the foot pedal is removed and operated from a remote location?”, or “Wouldn’t it be dangerous if the pedal was taken into the back of the machine where the machine could be operated?”. While both are valid concerns, additional safety technologies have been developed to provide both range and line-of-sight monitoring that ensure the distance and location of the foot pedal is always within pre-defined safety limits before the machine can be operated.

Range monitoring

Range monitoring enables the press brake manufacturer to set a maximum operating distance for individual pedals used on each machine. The range can be configured and set by the manufacturer, adding an extra level of safety by ensuring the machine can only be operated when the foot pedal is within a predetermined range. This eliminates the possibility of the machine being operated from a remote and potentially unsafe distance or location, that may otherwise put anyone within proximity of the machine at risk. Say if an operator was changing tools, or a worker was performing machine maintenance, they may be at risk of injury if another person attempted to cycle the machine from a remote location without their knowledge.

Line-of-sight monitoring

The addition of line-of-sight monitoring technology also enhances the level of safety. Ultrasonicsensors are integrated into the wireless foot pedal pendant as well as into the lower frame of the press brake. The press brake manufacturer sets the position, angle and direction of the ultrasonic sensors to create an operating zone for any wireless pedals that are connected to the machine.

What this does is prevents the machine from being operated if the pedal breaks line of sight with the ultrasonic sensors on the machine. For example, the press brake cannot be operated if the pedal was moved to the rear of the machine or hidden behind a wall or screen.

Solarcell Wireless Foot Pedal
This is a Solarcell Wireless Foot Pedal

Ergonomic design

The need for good ergonomic design is becoming increasingly important for press brake operators. Spending several hours each day standing in front of a press brake and manually handling material puts a great deal of physical strain on an operator. This can lead to physical and mental fatigue which in itself can be dangerous as a loss of concentration could lead to an operator making a mistake that could cause them an injury. Press brake manufacturers are constantly looking for ways to improve machine design and operating techniques in order to alleviate the strain on workers. While reductions in operator fatigue and improvements in accident minimisation is beneficial to a worker’s wellbeing, better ergonomic design will also have the added benefit of improved productivity.

Wireless technology now gives operators greater freedom to position the foot pedal anywhere across the front of the machine without the frustration of being tethered to a cable. This also helps with having the ability to easily set the pedal at a comfortable angle and especially beneficial when working with multiple tooling setups along the machine. With a wireless option, the operator can more easily move the pedal along the machine as they progress though each tooling station. Eliminating the foot pedal cable also frees up floor space so trolleys or carts used to transport and store material or completed parts can be positioned and moved around the press brake without restriction. Potential tripping hazards from cables lying across the floor are also eliminated, making for a safer and more efficient working environment.

Anyone that has ever experienced the inconvenience of a damaged foot pedal cable will know all too well the potential for significant machine downtime and lengthy production delays. Cable damage can be caused by heavy metal sheets being accidentally dropped or falling from the machine at the completion of a bend, striking and severing the pedal cable. While this may only damage the cable itself, in some cases a short circuited cable could potentially damage electronic components in the machine cabinet as well. In either case, any sort of cable damage causes major disruption to production until repairs are carried out and in some cases it could take several days before the machine is up and running again.

Improved ergonomic design, flexible functionality and improved productivity are just a few of the benefits that will be realised through wirelesspress brake foot pedal controls. Several leading press brake manufacturers including Salvagnini, LVD, ADIRA, Warcom, VICLA, STR, Schiavi and Vimercatti are already in the process of incorporating this new wireless technology. Look out for more information and details to be published on the Press Brake Buyer’s Guide website in the coming months.
